Oracle RAC 26 Ai Grid
###############################################################################
## Copyright(c) Oracle Corporation 1998,2025. All rights reserved. ##
## ##
## Specify values for the variables listed below to customize ##
## your installation. ##
## ##
## Each variable is associated with a comment. The comment ##
## can help to populate the variables with the appropriate ##
## values. ##
## ##
## IMPORTANT NOTE: This file contains plain text passwords and ##
## should be secured to have read permission only by oracle user ##
## or db administrator who owns this installation. ##
## ##
###############################################################################
###############################################################################
## ##
## Instructions to fill this response file ##
## To register and configure 'Grid Infrastructure for Cluster' ##
## - Fill out sections A,B,C,D,E,F and G ##
## - Fill out section G if OCR and Voting File should be placed on ASM ##
## ##
## To register and configure 'Grid Infrastructure for Standalone server' ##
## - Fill out sections A,B and G ##
## ##
## To register software for 'Grid Infrastructure' ##
## - Fill out sections A,B and D ##
## - Provide the cluster nodes in section D when choosing CRS_SWONLY as ##
## installation option in section A ##
## ##
## To upgrade clusterware and/or Automatic storage management of earlier ##
## releases ##
## - Fill out sections A,B,C,D and H ##
## ##
## To add more nodes to the cluster ##
## - Fill out sections A and D ##
## - Provide the cluster nodes in section D when choosing CRS_ADDNODE as ##
## installation option in section A ##
## ##
###############################################################################
#------------------------------------------------------------------------------
# Do not change the following system generated value.
#------------------------------------------------------------------------------
oracle.install.responseFileVersion=/oracle/install/rspfmt_crsinstall_response_schema_v23.0.0
###############################################################################
# #
# SECTION A - BASIC #
# #
###############################################################################
#-------------------------------------------------------------------------------
# Specify the location which holds the inventory files.
# This is an optional parameter if installing on
# Windows based Operating System.
#-------------------------------------------------------------------------------
INVENTORY_LOCATION=/oradb/app/oraInventory
#-------------------------------------------------------------------------------
# Specify the installation option.
# Allowed values: CRS_CONFIG or HA_CONFIG or UPGRADE or CRS_SWONLY or HA_SWONLY
# - CRS_CONFIG : To register home and configure Grid Infrastructure for cluster
# - HA_CONFIG : To register home and configure Grid Infrastructure for stand alone server
# - UPGRADE : To register home and upgrade clusterware software of earlier release
# - CRS_SWONLY : To register Grid Infrastructure Software home (can be configured for cluster
# or stand alone server later)
# - HA_SWONLY : To register Grid Infrastructure Software home (can be configured for stand
# alone server later. This is only supported on Windows.)
# - CRS_ADDNODE : To add more nodes to the cluster
# - CRS_DELETE_NODE : To delete nodes to the cluster
# - PATCH : To patch Grid Infrastructure Software
#
# Deprecated: oracle.install.option
#-------------------------------------------------------------------------------
installOption=CRS_CONFIG
#-------------------------------------------------------------------------------
# Specify the complete path of the Oracle Base.
#-------------------------------------------------------------------------------
ORACLE_BASE=/oradb/app/base
#-------------------------------------------------------------------------------
# Specify the usage for the cluster.
# Allowed values: RAC or GENERAL_PURPOSE
# - RAC : To configure cluster to manage Oracle RAC databases
# - GENERAL_PURPOSE : To configure cluster to manage generic applications
#
# Deprecated: oracle.install.crs.config.clusterUsage
#-------------------------------------------------------------------------------
clusterUsage=RAC
#-------------------------------------------------------------------------------
# Specify the patch options. Applicable only if PATCH is selected as install option.
# - zeroDowntimeGIPatching : Set true to use the zero downtime patching option
# - doNotUpdateDriver : Set true to skip updating ACFS drivers
#
# Deprecated: oracle.install.crs.patch.zeroDowntimeGIPatching
# Deprecated: oracle.install.crs.patch.doNotUpdateDriver
#-------------------------------------------------------------------------------
zeroDowntimeGIPatching=false
skipDriverUpdate=false
################################################################################
# #
# SECTION B - GROUPS #
# #
# The following three groups need to be assigned for all GI installations. #
# OSDBA and OSOPER can be the same or different. OSASM must be different #
# than the other two. #
# The value to be specified for OSDBA, OSOPER and OSASM group is only for #
# Unix based Operating System. #
# These groups are not required for upgrades, as they will be determined #
# from the Oracle home to upgrade. #
# #
################################################################################
#-------------------------------------------------------------------------------
# The OSDBA_GROUP is the OS group which is to be granted SYSDBA privileges.
#
# Deprecated: oracle.install.asm.OSDBA
#-------------------------------------------------------------------------------
OSDBA=dba
#-------------------------------------------------------------------------------
# The OSOPER_GROUP is the OS group which is to be granted SYSOPER privileges.
# The value to be specified for OSOPER group is optional.
# Value should not be provided if configuring Client Cluster - i.e. storageOption=CLIENT_ASM_STORAGE.
#
# Deprecated: oracle.install.asm.OSOPER
#-------------------------------------------------------------------------------
OSOPER=dba
#-------------------------------------------------------------------------------
# The OSASM_GROUP is the OS group which is to be granted SYSASM privileges. This
# must be different than the previous two.
#
# Deprecated: oracle.install.asm.OSASM
#-------------------------------------------------------------------------------
OSASM=dba
################################################################################
# #
# SECTION C - SCAN #
# #
################################################################################
#-------------------------------------------------------------------------------
# Specify the type of SCAN configuration for the cluster
# Allowed values : LOCAL_SCAN and SHARED_SCAN
#
# Deprecated: oracle.install.crs.config.scanType
#-------------------------------------------------------------------------------
scanType=LOCAL_SCAN
#-------------------------------------------------------------------------------
# Applicable only if SHARED_SCAN is being configured for cluster
# Specify the path to the SCAN client data file
#
# Deprecated: oracle.install.crs.config.SCANClientDataFile
#-------------------------------------------------------------------------------
scanClientDataFile=
#-------------------------------------------------------------------------------
# Specify a name for SCAN
# Applicable if LOCAL_SCAN is being configured for the cluster
# If you choose to configure the cluster with GNS with Auto assigned Node VIPs(DHCP),then the scanName should be specified in the format of 'SCAN name.Cluster name.GNS sub-domain'
#
# Deprecated: oracle.install.crs.config.gpnp.scanName
#-------------------------------------------------------------------------------
scanName=racdb-scan
#-------------------------------------------------------------------------------
# Specify a unused port number for SCAN service
#
# Deprecated: oracle.install.crs.config.gpnp.scanPort
#-------------------------------------------------------------------------------
scanPort=1521
################################################################################
# #
# SECTION D - CLUSTER & GNS #
# #
################################################################################
#-------------------------------------------------------------------------------
# Specify 'true' if you would like to configure the cluster as Extended, else
# specify 'false'
#
# Deprecated: oracle.install.crs.config.configureAsExtendedCluster
#-------------------------------------------------------------------------------
configureAsExtendedCluster=false
#-------------------------------------------------------------------------------
# Specify a name for the Cluster you are creating.
#
# The maximum length allowed for clustername is 63 characters. The name can be
# any combination of lower and uppercase alphabets (A - Z), (0 - 9) and hyphens (-).
#
# Deprecated: oracle.install.crs.config.clusterName
#-------------------------------------------------------------------------------
clusterName=racdb
#-------------------------------------------------------------------------------
# Specify 'true' if you would like to configure Grid Naming Service(GNS), else
# specify 'false'
#
# Deprecated: oracle.install.crs.config.gpnp.configureGNS
#-------------------------------------------------------------------------------
configureGNS=false
#-------------------------------------------------------------------------------
# Specify 'true' if you would like to assign SCAN name VIP and Node VIPs by DHCP
# , else specify 'false'
#
# Deprecated: oracle.install.crs.config.autoConfigureClusterNodeVIP
#-------------------------------------------------------------------------------
configureDHCPAssignedVIPs=false
#-------------------------------------------------------------------------------
# Applicable only if you choose to configure GNS.
# Specify the GNS subdomain and an unused virtual hostname for GNS service
#
# Deprecated: oracle.install.crs.config.gpnp.gnsSubDomain
# Deprecated: oracle.install.crs.config.gpnp.gnsVIPAddress
#-------------------------------------------------------------------------------
gnsSubDomain=
gnsVIPAddress=
#-------------------------------------------------------------------------------
# Specify the list of sites - only if configuring an Extended Cluster
#
# Deprecated: oracle.install.crs.config.sites
#-------------------------------------------------------------------------------
sites=
#-------------------------------------------------------------------------------
# Specify the list of nodes that have to be configured to be part of the cluster.
#
# The list should a comma-separated list of tuples. Each tuple should be a
# colon-separated string that contains
# - 1 field if you have chosen CRS_SWONLY as installation option, or
# - 2 fields if configuring a Flex Cluster
# - 2 fields if adding more nodes to the configured cluster, or
# - 3 fields if configuring an Extended Cluster
#
# The fields should be ordered as follows:
# 1. The first field should be the public node name.
# 2. The second field should be the virtual host name
# (Should be specified as AUTO if you have chosen 'auto configure for VIP'
# i.e. configureDHCPAssignedVIPs=true)
# 3. The third field indicates the site designation for the node. To be specified only if configuring an Extended Cluster.
# Only the 1st field is applicable if you have chosen CRS_SWONLY as installation option
#
# Examples
# For registering GI for a cluster software: clusterNodes=node1,node2
# For adding more nodes to the configured cluster: clusterNodes=node1:node1-vip,node2:node2-vip
# For configuring Flex Cluster: clusterNodes=node1:node1-vip,node2:node2-vip
# For configuring General Purpose Cluster (GPC): clusterNodes=node1:,node2:
# For configuring Extended Cluster: clusterNodes=node1:node1-vip:site1,node2:node2-vip:site2
# You can specify a range of nodes in the tuple using colon separated fields of format
# hostnameprefix:lowerbound-upperbound:hostnamesuffix:vipsuffix
#
# Deprecated: oracle.install.crs.config.clusterNodes
#-------------------------------------------------------------------------------
clusterNodes=rac1:rac1-vip,rac2:rac2-vip
#-------------------------------------------------------------------------------
# The value should be a comma separated strings where each string is as shown below
# InterfaceName:SubnetAddress:InterfaceType
# where InterfaceType can be either "1", "2", "3", "4", or "5"
# InterfaceType stand for the following values
# - 1 : PUBLIC
# - 2 : PRIVATE
# - 3 : DO NOT USE
# - 4 : ASM
# - 5 : ASM & PRIVATE
# - 6 : ALL (Not available for RAC usage)
#
# For example: eth0:140.87.24.0:1,eth1:10.2.1.0:2,eth2:140.87.52.0:3
#
# Deprecated: oracle.install.crs.config.networkInterfaceList
#-------------------------------------------------------------------------------
networkInterfaceList=enp0s3:10.10.10.0:1,enp0s8:192.168.56.0:5,enp0s9:192.168.57.0:3,enp0s10:192.168.58.0:3
################################################################################
# #
# SECTION E - STORAGE #
# #
################################################################################
#-------------------------------------------------------------------------------
# Specify the type of storage to use for Oracle Cluster Registry(OCR) and Voting Files.
# - FLEX_ASM_STORAGE
# - CLIENT_ASM_STORAGE
# - FILE_SYSTEM_STORAGE
# - EXASCALE_STORAGE
#
# Deprecated: oracle.install.crs.config.storageOption
#-------------------------------------------------------------------------------
storageOption=FLEX_ASM_STORAGE
#-------------------------------------------------------------------------------
# These properties are applicable only if FILE_SYSTEM_STORAGE is chosen for
# storing OCR and Voting File
# Specify the location(s) for OCR and Voting Files
# Three(3) or one(1) location(s) should be specified for OCR and Voting File,
# separated by commas.
# Example:
# For Unix based Operating System:
# votingFilesLocations=/oradbocfs/storage/vfile1,/oradbocfs/storage/vfile2,/oradbocfs/storage/vfile3
# ocrLocations=/oradbocfs/storage/ocr1,/oradbocfs/storage/ocr2,/oradbocfs/storage/ocr3
# For Windows based Operating System OCR/VFILE on shared storage is not supported.
#
# Deprecated: oracle.install.crs.config.sharedFileSystemStorage.votingDiskLocations
# Deprecated: oracle.install.crs.config.sharedFileSystemStorage.ocrLocations
#-------------------------------------------------------------------------------
votingFilesLocations=
ocrLocations=
#-------------------------------------------------------------------------------
# Applicable only if configuring CLIENT_ASM_STORAGE for OCR/Voting File storage
# Specify the path to Client ASM Data file
#
# Deprecated: oracle.install.asm.ClientDataFile
#-------------------------------------------------------------------------------
clientDataFile=
################################################################################
# #
# SECTION F - IPMI #
# #
################################################################################
#-------------------------------------------------------------------------------
# Specify 'true' if you would like to configure Intelligent Power Management interface
# (IPMI), else specify 'false'
#
# Deprecated: oracle.install.crs.config.useIPMI
#-------------------------------------------------------------------------------
useIPMI=false
#-------------------------------------------------------------------------------
# Applicable only if you choose to configure IPMI
# i.e. useIPMI=true
# Specify the location of the ipmiutil binary
# Specify the username and password for using IPMI service
#
# Deprecated: oracle.install.crs.config.ipmi.bmcBinpath
# Deprecated: oracle.install.crs.config.ipmi.bmcUsername
# Deprecated: oracle.install.crs.config.ipmi.bmcPassword
#-------------------------------------------------------------------------------
bmcBinpath=
bmcUsername=
bmcPassword=
################################################################################
# #
# SECTION G - ASM #
# #
################################################################################
#-------------------------------------------------------------------------------
# Password for SYS user of Oracle ASM
#
# Deprecated: oracle.install.asm.SYSASMPassword
#-------------------------------------------------------------------------------
sysasmPassword=
#-------------------------------------------------------------------------------
# The ASM DiskGroup
#
# Example: diskGroupName=data
#
# Deprecated: oracle.install.asm.diskGroup.name
#-------------------------------------------------------------------------------
diskGroupName=OCRVOTE
#-------------------------------------------------------------------------------
# Redundancy level to be used by ASM.
# It can be one of the following
# - NORMAL
# - HIGH
# - EXTERNAL
# - FLEX
# - EXTENDED (only if configureAsExtendedCluster=true)
# Example: redundancy=NORMAL
#
# Deprecated: oracle.install.asm.diskGroup.redundancy
#-------------------------------------------------------------------------------
redundancy=NORMAL
#-------------------------------------------------------------------------------
# Allocation unit size to be used by ASM.
# It can be one of the following values
# - 1
# - 2
# - 4
# - 8
# - 16
# - 32
# - 64
# Example: auSize=4
# size unit is MB
#
# Deprecated: oracle.install.asm.diskGroup.AUSize
#-------------------------------------------------------------------------------
auSize=4
#-------------------------------------------------------------------------------
# Failure Groups for the disk group
# If configuring for Extended cluster specify as list of "failure group name:site"
# tuples.
# Else just specify as list of failure group names
#
# Deprecated: oracle.install.asm.diskGroup.FailureGroups
#-------------------------------------------------------------------------------
failureGroups=
#-------------------------------------------------------------------------------
# List of disks and their failure groups to create a ASM DiskGroup
# (Use this if each of the disks have an associated failure group)
# Failure Groups are not required if redundancy=EXTERNAL
# Example:
# For Unix based Operating System:
# disksWithFailureGroupNames=/oracle/asm/disk1,FGName,/oracle/asm/disk2,FGName
# For Windows based Operating System:
# disksWithFailureGroupNames=\\.\ORCLDISKDATA0,FGName,\\.\ORCLDISKDATA1,FGName
#
# Deprecated: oracle.install.asm.diskGroup.disksWithFailureGroupNames
#-------------------------------------------------------------------------------
disksWithFailureGroupNames=/dev/oracleasm/asm-disk01,,/dev/oracleasm/asm-disk02,,/dev/oracleasm/asm-disk03,
#-------------------------------------------------------------------------------
# List of disks to create a ASM DiskGroup
# (Use this variable only if failure groups configuration is not required)
# Example:
# For Unix based Operating System:
# diskList=/oracle/asm/disk1,/oracle/asm/disk2
# For Windows based Operating System:
# diskList=\\.\ORCLDISKDATA0,\\.\ORCLDISKDATA1
#
# Deprecated: oracle.install.asm.diskGroup.disks
#-------------------------------------------------------------------------------
diskList=/dev/oracleasm/asm-disk01,/dev/oracleasm/asm-disk02,/dev/oracleasm/asm-disk03
#-------------------------------------------------------------------------------
# List of failure groups to be marked as QUORUM.
# Quorum failure groups contain only Voting File, no user data is stored
# Example:
# quorumFailureGroupNames=FGName1,FGName2
#
# Deprecated: oracle.install.asm.diskGroup.quorumFailureGroupNames
#-------------------------------------------------------------------------------
quorumFailureGroupNames=
#-------------------------------------------------------------------------------
# The disk discovery string to be used to discover the disks used create a ASM DiskGroup
#
# Example:
# For Unix based Operating System:
# diskString=/oracle/asm/*
# For Windows based Operating System:
# diskString=\\.\ORCLDISK*
#
# Note: Refrain from enclosing the disk discovery string with single quotes (' ') or double quotes (" ").
#
# Deprecated: oracle.install.asm.diskGroup.diskDiscoveryString
#-------------------------------------------------------------------------------
diskString=/dev/oracleasm/*
#-------------------------------------------------------------------------------
# Password for ASMSNMP account
# ASMSNMP account is used by Oracle Enterprise Manager to monitor Oracle ASM instances
#
# Deprecated: oracle.install.asm.monitorPassword
#-------------------------------------------------------------------------------
asmsnmpPassword=
################################################################################
# #
# SECTION H - UPGRADE #
# #
################################################################################
#-------------------------------------------------------------------------------
# Specify whether to ignore down nodes during upgrade operation.
# Value should be 'true' to ignore down nodes otherwise specify 'false'
#
# Deprecated: oracle.install.crs.config.ignoreDownNodes
#-------------------------------------------------------------------------------
ignoreDownNodes=false
################################################################################
# #
# SECTION I - OCR BACKUP #
# #
################################################################################
#------------------------------------------------------------------------------
# Create a separate ASM DiskGroup to store Clusterware data.
# Specify 'true' if you would like to store backup of Clusterware data,
# else specify 'false'
# Value can be true/false.
#------------------------------------------------------------------------------
configureBackupDG=false
#-------------------------------------------------------------------------------
# Backup Storage data ASM DiskGroup
# Applicable only when
# configureBackupDG=true
# Example: backupDGName=RECO
#-------------------------------------------------------------------------------
backupDGName=RECO
#-------------------------------------------------------------------------------
# Redundancy level to be used by ASM.
# It can be one of the following
# - NORMAL
# - HIGH
# - EXTERNAL
# - FLEX
# - EXTENDED (only if configureAsExtendedCluster=true)
# Example: backupDGRedundancy=NORMAL
#-------------------------------------------------------------------------------
backupDGRedundancy=NORMAL
#-------------------------------------------------------------------------------
# Allocation unit size to be used by ASM.
# It can be one of the following values
# - 1
# - 2
# - 4
# - 8
# - 16
# - 32
# - 64
# Example: backupDGAUSize=4
# size unit is MB
#-------------------------------------------------------------------------------
backupDGAUSize=4
#-------------------------------------------------------------------------------
# Failure Groups for the backup storage data ASM disk group
# If configuring for Extended cluster specify as list of "failure group name:site"
# tuples.
# Else just specify as list of failure group names
#-------------------------------------------------------------------------------
backupDGFailureGroups=
#-------------------------------------------------------------------------------
# List of disks and their failure groups to create backup data ASM DiskGroup
# (Use this if each of the disks have an associated failure group)
# Failure Groups are not required if backupDGRedundancy=EXTERNAL
# Example:
# For Unix based Operating System:
# backupDGDisksWithFailureGroupNames=/oracle/asm/disk1,FGName,/oracle/asm/disk2,FGName
# For Windows based Operating System:
# backupDGDisksWithFailureGroupNames=\\.\ORCLDISKDATA0,FGName,\\.\ORCLDISKDATA1,FGName
#-------------------------------------------------------------------------------
backupDGDisksWithFailureGroupNames=
#-------------------------------------------------------------------------------
# List of disks to create backup data ASM DiskGroup
# (Use this variable only if failure groups configuration is not required)
# Example:
# For Unix based Operating System:
# backupDGDiskList=/oracle/asm/disk1,/oracle/asm/disk2
# For Windows based Operating System:
# backupDGDiskList=\\.\ORCLDISKDATA0,\\.\ORCLDISKDATA1
#-------------------------------------------------------------------------------
backupDGDiskList=
#-------------------------------------------------------------------------------
# List of failure groups to be marked as QUORUM.
# Quorum failure groups contain only Voting File, no user data is stored
# Example:
# backupDGQuorumFailureGroups=FGName1,FGName2
#-------------------------------------------------------------------------------
backupDGQuorumFailureGroups=
################################################################################
# #
# MANAGEMENT OPTIONS #
# #
################################################################################
#-------------------------------------------------------------------------------
# Specify the management option to use for managing Oracle Grid Infrastructure
# Options are:
# 1. CLOUD_CONTROL - If you want to manage your Oracle Grid Infrastructure with Enterprise Manager Cloud Control.
# 2. NONE -If you do not want to manage your Oracle Grid Infrastructure with Enterprise Manager Cloud Control.
#
# Deprecated: oracle.install.config.managementOption
#-------------------------------------------------------------------------------
managementOption=NONE
#-------------------------------------------------------------------------------
# Specify the OMS host to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.config.omsHost
#-------------------------------------------------------------------------------
omsHost=
#-------------------------------------------------------------------------------
# Specify the OMS port to connect to Cloud Control.
# Applicable only when oracle.install.config.managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.config.omsPort
#-------------------------------------------------------------------------------
omsPort=0
#-------------------------------------------------------------------------------
# Specify the EM Admin user name to use to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.config.emAdminUser
#-------------------------------------------------------------------------------
emAdminUser=
#-------------------------------------------------------------------------------
# Specify the EM Admin password to use to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.config.emAdminPassword
#-------------------------------------------------------------------------------
emAdminPassword=
################################################################################
# #
# Root script execution configuration #
# #
################################################################################
#-------------------------------------------------------------------------------------------------------
# Specify the root script execution mode.
#
# - true : To run the root script automatically by using the appropriate configuration methods.
# - false : To run the root script manually.
#
# If this option is selected, password should be specified on the console.
#
# Deprecated: oracle.install.crs.rootconfig.executeRootScript
#-------------------------------------------------------------------------------------------------------
executeRootScript=false
#--------------------------------------------------------------------------------------
# Specify the configuration method to be used for automatic root script execution.
#
# Following are the possible choices:
# - ROOT
# - SUDO
#
# Deprecated: oracle.install.crs.rootconfig.configMethod
#--------------------------------------------------------------------------------------
configMethod=
#--------------------------------------------------------------------------------------
# Specify the absolute path of the sudo program.
#
# Applicable only when SUDO configuration method was chosen.
#
# Deprecated: oracle.install.crs.rootconfig.sudoPath
#--------------------------------------------------------------------------------------
sudoPath=/usr/local/bin/sudo
#--------------------------------------------------------------------------------------
# Specify the name of the user who is in the sudoers list.
# Applicable only when SUDO configuration method was chosen.
# Note:For Grid Infrastructure for Standalone server installations,the sudo user name must be the username of the user performing the installation.
#
# Deprecated: oracle.install.crs.rootconfig.sudoUserName
#--------------------------------------------------------------------------------------
sudoUserName=oracle
#--------------------------------------------------------------------------------------
# Specify the nodes batch map.
#
# This should be a comma separated list of node:batch pairs.
# During upgrade, you can sequence the automatic execution of root scripts
# by pooling the nodes into batches.
# A maximum of three batches can be specified.
# Installer will execute the root scripts on all the nodes in one batch before
# proceeding to next batch.
# Root script execution on the local node must be in Batch 1.
# Examples:
# 1. batchInfo=Node1:1,Node2:2,Node3:2,Node4:3
# 2. batchInfo=Node1:1,Node2:2,Node3:2,Node4:2
# 3. batchInfo=Node1:1,Node2:1,Node3:2,Node4:3
#
# Applicable only for UPGRADE install option.
#
# Deprecated: oracle.install.crs.config.batchinfo
#--------------------------------------------------------------------------------------
batchInfo=
#################################################################################
# #
# DELETE NODE OPTIONS #
# #
#################################################################################
#--------------------------------------------------------------------------------
# Specify the node names to delete nodes from cluster.
# Delete node will be performed only for the remote nodes from the cluster.
#
# Deprecated: oracle.install.crs.deleteNode.nodes
#--------------------------------------------------------------------------------
nodesToDelete=
#-------------------------------------------------------------------------------
# Specify 'true' if you would like to configure Automatic Self Correction, else
# specify 'false'
#
# Deprecated: oracle.install.crs.EnableAutoFixup
#-------------------------------------------------------------------------------
enableAutoFixup=false
Oracle DB 26Ai Software Only(RAC 기반)
####################################################################
## Copyright(c) Oracle Corporation 1998,2025. All rights reserved.##
## ##
## Specify values for the variables listed below to customize ##
## your installation. ##
## ##
## Each variable is associated with a comment. The comment ##
## can help to populate the variables with the appropriate ##
## values. ##
## ##
## IMPORTANT NOTE: This file contains plain text passwords and ##
## should be secured to have read permission only by oracle user ##
## or db administrator who owns this installation. ##
## ##
####################################################################
#------------------------------------------------------------------------------
# Do not change the following system generated value.
#------------------------------------------------------------------------------
oracle.install.responseFileVersion=/oracle/install/rspfmt_dbinstall_response_schema_v23.0.0
#-------------------------------------------------------------------------------
# Specify the installation option.
# It can be one of the following:
# - INSTALL_DB_SWONLY
# - INSTALL_DB_AND_CONFIG
#
# Deprecated: oracle.install.option
#-------------------------------------------------------------------------------
installOption=INSTALL_DB_SWONLY
#-------------------------------------------------------------------------------
# Specify the Unix group to be set for the inventory directory.
#-------------------------------------------------------------------------------
UNIX_GROUP_NAME=dba
#-------------------------------------------------------------------------------
# Specify the location which holds the inventory files.
# This is an optional parameter if installing on
# Windows based Operating System.
#-------------------------------------------------------------------------------
INVENTORY_LOCATION=/oradb/app/oraInventory
#-------------------------------------------------------------------------------
# Specify the complete path of the Oracle Base.
#-------------------------------------------------------------------------------
ORACLE_BASE=/oradb/app/base
#-------------------------------------------------------------------------------
# Specify the installation edition of the component.
#
# The value should contain only one of these choices.
# - EE : Enterprise Edition
#
# Deprecated: oracle.install.db.InstallEdition
#-------------------------------------------------------------------------------
installEdition=EE
###############################################################################
# #
# PRIVILEGED OPERATING SYSTEM GROUPS #
# ------------------------------------------ #
# Provide values for the OS groups to which SYSDBA and SYSOPER privileges #
# needs to be granted. If the install is being performed as a member of the #
# group "dba", then that will be used unless specified otherwise below. #
# #
# The value to be specified for OSDBA and OSOPER group is only for UNIX based #
# Operating System. #
# #
###############################################################################
#------------------------------------------------------------------------------
# The OSDBA is the OS group which is to be granted SYSDBA privileges.
#
# Deprecated: oracle.install.db.OSDBA_GROUP
#-------------------------------------------------------------------------------
OSDBA=dba
#------------------------------------------------------------------------------
# The OSOPER is the OS group which is to be granted SYSOPER privileges.
# The value to be specified for OSOPER group is optional.
#
# Deprecated: oracle.install.db.OSOPER_GROUP
#------------------------------------------------------------------------------
OSOPER=dba
#------------------------------------------------------------------------------
# The OSBACKUPDBA is the OS group which is to be granted SYSBACKUP privileges.
#
# Deprecated: oracle.install.db.OSBACKUPDBA_GROUP
#------------------------------------------------------------------------------
OSBACKUPDBA=dba
#------------------------------------------------------------------------------
# The OSDGDBA is the OS group which is to be granted SYSDG privileges.
#
# Deprecated: oracle.install.db.OSDGDBA_GROUP
#------------------------------------------------------------------------------
OSDGDBA=dba
#------------------------------------------------------------------------------
# The OSKMDBA is the OS group which is to be granted SYSKM privileges.
#
# Deprecated: oracle.install.db.OSKMDBA_GROUP
#------------------------------------------------------------------------------
OSKMDBA=dba
#------------------------------------------------------------------------------
# The OSRACDBA is the OS group which is to be granted SYSRAC privileges.
#
# Deprecated: oracle.install.db.OSRACDBA_GROUP
#------------------------------------------------------------------------------
OSRACDBA=dba
################################################################################
# #
# Root script execution configuration #
# #
################################################################################
#-------------------------------------------------------------------------------------------------------
# Specify the root script execution mode.
#
# - true : To run the root script automatically by using the appropriate configuration methods.
# - false : To run the root script manually.
#
# If this option is selected, password should be specified on the console.
#
# Deprecated: oracle.install.db.rootconfig.executeRootScript
#-------------------------------------------------------------------------------------------------------
executeRootScript=
#--------------------------------------------------------------------------------------
# Specify the configuration method to be used for automatic root script execution.
#
# Following are the possible choices:
# - ROOT
# - SUDO
#
# Deprecated: oracle.install.db.rootconfig.configMethod
#--------------------------------------------------------------------------------------
configMethod=
#--------------------------------------------------------------------------------------
# Specify the absolute path of the sudo program.
#
# Applicable only when SUDO configuration method was chosen.
#
# Deprecated: oracle.install.db.rootconfig.sudoPath
#--------------------------------------------------------------------------------------
sudoPath=
#--------------------------------------------------------------------------------------
# Specify the name of the user who is in the sudoers list.
# Applicable only when SUDO configuration method was chosen.
# Note:For Single Instance database installations,the sudo user name must be the username of the user installing the database.
#
# Deprecated: oracle.install.db.rootconfig.sudoUserName
#--------------------------------------------------------------------------------------
sudoUserName=
###############################################################################
# #
# Grid Options #
# #
###############################################################################
#------------------------------------------------------------------------------
# Value is required only if the specified install option is INSTALL_DB_SWONLY
#
# Specify the cluster nodes to deploy Enterprise Edition Real Application
# Cluster Database Oracle Home software.
#
# Example : clusterNodes=node1,node2
#
# Deprecated: oracle.install.db.CLUSTER_NODES
#------------------------------------------------------------------------------
clusterNodes=rac1,rac2
###############################################################################
# #
# Database Configuration Options #
# #
###############################################################################
#-------------------------------------------------------------------------------
# Specify the type of database to create.
# It can be one of the following:
# - GENERAL_PURPOSE
# - DATA_WAREHOUSE
# GENERAL_PURPOSE: A starter database designed for general purpose use or transaction-heavy applications.
# DATA_WAREHOUSE : A starter database optimized for data warehousing applications.
#
# Deprecated: oracle.install.db.config.starterdb.type
#-------------------------------------------------------------------------------
dbType=GENERAL_PURPOSE
#-------------------------------------------------------------------------------
# Specify the Starter Database Global Database Name.
#
# Deprecated: oracle.install.db.config.starterdb.globalDBName
#-------------------------------------------------------------------------------
gdbName=
#-------------------------------------------------------------------------------
# Specify the Starter Database SID.
#
# Deprecated: oracle.install.db.config.starterdb.SID
#-------------------------------------------------------------------------------
dbSID=
#-------------------------------------------------------------------------------
# Specify the Pluggable Database name for the pluggable database in Container Database.
#
# Deprecated: oracle.install.db.config.PDBName
#-------------------------------------------------------------------------------
pdbName=
#-------------------------------------------------------------------------------
# Specify the Starter Database character set.
#
# One of the following
# AL32UTF8, WE8ISO8859P15, WE8MSWIN1252, EE8ISO8859P2,
# EE8MSWIN1250, NE8ISO8859P10, NEE8ISO8859P4, BLT8MSWIN1257,
# BLT8ISO8859P13, CL8ISO8859P5, CL8MSWIN1251, AR8ISO8859P6,
# AR8MSWIN1256, EL8ISO8859P7, EL8MSWIN1253, IW8ISO8859P8,
# IW8MSWIN1255, JA16EUC, JA16EUCTILDE, JA16SJIS, JA16SJISTILDE,
# KO16MSWIN949, ZHS16GBK, TH8TISASCII, ZHT32EUC, ZHT16MSWIN950,
# ZHT16HKSCS, WE8ISO8859P9, TR8MSWIN1254, VN8MSWIN1258
#
# Deprecated: oracle.install.db.config.starterdb.characterSet
#-------------------------------------------------------------------------------
charSet=
#------------------------------------------------------------------------------
# This variable should be set to true if Automatic Memory Management
# in Database is desired.
# If Automatic Memory Management is not desired, and memory allocation
# is to be done manually, then set it to false.
#
# Deprecated: oracle.install.db.config.starterdb.memoryOption
#------------------------------------------------------------------------------
enableAutoMemoryManagement=false
#-------------------------------------------------------------------------------
# Specify the total memory allocation for the database. Value(in MB) should be
# at least 256 MB, and should not exceed the total physical memory available
# on the system.
# Example: memoryLimit=512
#
# Deprecated: oracle.install.db.config.starterdb.memoryLimit
#-------------------------------------------------------------------------------
memoryLimit=
###############################################################################
# #
# Passwords can be supplied for the following four system accounts in the #
# starter database: #
# SYS #
# SYSTEM #
# DBSNMP (used by Enterprise Manager) #
# PDBADMIN #
# #
# Same password can be used for all accounts (not recommended) #
# or different passwords for each account can be provided (recommended) #
# #
###############################################################################
#------------------------------------------------------------------------------
# This variable holds the password that is to be used for all schemas in the
# starter database.
#
# Deprecated: oracle.install.db.config.starterdb.password.ALL
#-------------------------------------------------------------------------------
allSchemaPassword=
#-------------------------------------------------------------------------------
# Specify the SYS password for the starter database.
#
# Deprecated: oracle.install.db.config.starterdb.password.SYS
#-------------------------------------------------------------------------------
sysPassword=
#-------------------------------------------------------------------------------
# Specify the SYSTEM password for the starter database.
#
# Deprecated: oracle.install.db.config.starterdb.password.SYSTEM
#-------------------------------------------------------------------------------
systemPassword=
#-------------------------------------------------------------------------------
# Specify the DBSNMP password for the starter database.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.db.config.starterdb.password.DBSNMP
#-------------------------------------------------------------------------------
dbsnmpPassword=
#-------------------------------------------------------------------------------
# Specify the PDBADMIN password required for creation of Pluggable Database in the Container Database.
#
# Deprecated: oracle.install.db.config.starterdb.password.PDBADMIN
#-------------------------------------------------------------------------------
pdbadminPassword=
#-------------------------------------------------------------------------------
# Specify the management option to use for managing the database.
# Options are:
# 1. CLOUD_CONTROL - If you want to manage your database with Enterprise Manager Cloud Control.
# 2. NONE -If you do not want to manage your database with Enterprise Manager Cloud Control.
#
# Deprecated: oracle.install.db.config.starterdb.managementOption
#-------------------------------------------------------------------------------
managementOption=
#-------------------------------------------------------------------------------
# Specify the OMS host to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.db.config.starterdb.omsHost
#-------------------------------------------------------------------------------
omsHost=
#-------------------------------------------------------------------------------
# Specify the OMS port to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.db.config.starterdb.omsPort
#-------------------------------------------------------------------------------
omsPort=0
#-------------------------------------------------------------------------------
# Specify the EM Admin user name to use to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.db.config.starterdb.emAdminUser
#-------------------------------------------------------------------------------
emAdminUser=
#-------------------------------------------------------------------------------
# Specify the EM Admin password to use to connect to Cloud Control.
# Applicable only when managementOption=CLOUD_CONTROL
#
# Deprecated: oracle.install.db.config.starterdb.emAdminPassword
#-------------------------------------------------------------------------------
emAdminPassword=
###############################################################################
# #
# SPECIFY RECOVERY OPTIONS #
# ------------------------------------ #
# Recovery options for the database can be mentioned using the entries below #
# #
###############################################################################
#------------------------------------------------------------------------------
# This variable is to be set to false if database recovery is not required. Else
# this can be set to true.
#
# Deprecated: oracle.install.db.config.starterdb.enableRecovery
#-------------------------------------------------------------------------------
enableRecovery=false
#-------------------------------------------------------------------------------
# Specify the type of storage to use for the database.
# It can be one of the following:
# - FILE_SYSTEM_STORAGE
# - ASM_STORAGE
#
# Deprecated: oracle.install.db.config.starterdb.storageType
#-------------------------------------------------------------------------------
storageType=
#-------------------------------------------------------------------------------
# Specify the database file location which is a directory for datafiles, control
# files, redo logs.
#
# Applicable only when storageType=FILE_SYSTEM_STORAGE
#
# Deprecated: oracle.install.db.config.starterdb.fileSystemStorage.dataLocation
#-------------------------------------------------------------------------------
dataLocation=
#-------------------------------------------------------------------------------
# Specify the recovery location.
#
# Applicable only when storageType=FILE_SYSTEM_STORAGE
#
# Deprecated: oracle.install.db.config.starterdb.fileSystemStorage.recoveryLocation
#-------------------------------------------------------------------------------
recoveryLocation=
#-------------------------------------------------------------------------------
# Specify the existing ASM disk groups to be used for storage.
#
# Applicable only when storageType=ASM_STORAGE
#
# Deprecated: oracle.install.db.config.asm.diskGroup
#-------------------------------------------------------------------------------
diskGroup=
#-------------------------------------------------------------------------------
# Specify the password for ASMSNMP user of the ASM instance.
#
# Applicable only when storageType=ASM_STORAGE
#
# Deprecated: oracle.install.db.config.asm.ASMSNMPPassword
#-------------------------------------------------------------------------------
asmsnmpPassword=
Oracle RAC 26 Ai DBCA
##############################################################################
## ##
## DBCA response file ##
## ------------------ ##
## Copyright(c) Oracle Corporation 1998,2025. All rights reserved. ##
## ##
## Specify values for the variables listed below to customize ##
## your installation. ##
## ##
## Each variable is associated with a comment. The comment ##
## can help to populate the variables with the appropriate ##
## values. ##
## ##
## IMPORTANT NOTE: This file contains plain text passwords and ##
## should be secured to have read permission only by oracle user ##
## or db administrator who owns this installation. ##
##############################################################################
#-------------------------------------------------------------------------------
# Do not change the following system generated value.
#-------------------------------------------------------------------------------
responseFileVersion=/oracle/assistants/rspfmt_dbca_response_schema_v23.0.0
#-----------------------------------------------------------------------------
# Name : gdbName
# Datatype : String
# Description : Global database name of the database
# Valid values : <db_name>.<db_domain> - when database domain isn't NULL
# <db_name> - when database domain is NULL
# Default value : None
# Mandatory : Yes
#-----------------------------------------------------------------------------
gdbName=CDB
#-----------------------------------------------------------------------------
# Name : sid
# Datatype : String
# Description : System identifier (SID) of the database
# Valid values : Check Oracle12c Administrator's Guide
# Default value : <db_name> specified in GDBNAME
# Mandatory : No
#-----------------------------------------------------------------------------
sid=CDB
#-----------------------------------------------------------------------------
# Name : databaseConfigType
# Datatype : String
# Description : database conf type as Single Instance, Real Application Cluster, Real Application Cluster One Nodes database or Standard Edition High Availability
# Valid values : SI\RAC\RACONENODE\SEHA
# Default value : SI
# Mandatory : No
#-----------------------------------------------------------------------------
databaseConfigType=RAC
#-----------------------------------------------------------------------------
# Name : RACOneNodeServiceName
# Datatype : String
# Description : Service is required by application to connect to RAC One
# Node Database
# Valid values : Service Name
# Default value : None
# Mandatory : No [required in case DATABASECONFTYPE is set to RACONENODE ]
#-----------------------------------------------------------------------------
RACOneNodeServiceName=
#-----------------------------------------------------------------------------
# Name : sehaServiceName
# Datatype : String
# Description : Service is required by application to connect to SEHA Database
# Valid values : SEHA Service Name
# Default value : None
# Mandatory : No [required in case DATABASECONFTYPE is set to SEHA ]
#-----------------------------------------------------------------------------
sehaServiceName=
#-----------------------------------------------------------------------------
# Name : policyManaged
# Datatype : Boolean
# Description : Set to true if Database is policy managed and
# set to false if Database is admin managed
# Valid values : TRUE\FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
policyManaged=false
#-----------------------------------------------------------------------------
# Name : managementPolicy
# Datatype : String
# Description : Set to AUTOMATIC or RANK based on management policy.
# Valid values : AUTOMATIC\RANK
# Default value : AUTOMATIC
# Mandatory : No
#-----------------------------------------------------------------------------
managementPolicy=AUTOMATIC
#-----------------------------------------------------------------------------
# Name : createServerPool
# Datatype : Boolean
# Description : Set to true if new server pool need to be created for database
# if this option is specified then the newly created database
# will use this newly created serverpool.
# Multiple serverpoolname can not be specified for database
# Valid values : TRUE\FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
createServerPool=false
#-----------------------------------------------------------------------------
# Name : serverPoolName
# Datatype : String
# Description : Only one serverpool name need to be specified
# if Create Server Pool option is specified.
# Comma-separated list of Serverpool names if db need to use
# multiple Server pool
# Valid values : ServerPool name
# Default value : None
# Mandatory : No [required in case of RAC service centric database]
#-----------------------------------------------------------------------------
serverPoolName=
#-----------------------------------------------------------------------------
# Name : cardinality
# Datatype : Number
# Description : Specify Cardinality for create server pool operation
# Valid values : any positive Integer value
# Default value : Number of qualified nodes on cluster
# Mandatory : No [Required when a new serverpool need to be created]
#-----------------------------------------------------------------------------
cardinality=
#-----------------------------------------------------------------------------
# Name : force
# Datatype : Boolean
# Description : Set to true if new server pool need to be created by force
# if this option is specified then the newly created serverpool
# will be assigned server even if no free servers are available.
# This may affect already running database.
# This flag can be specified for Admin managed as well as policy managed db.
# Valid values : TRUE\FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
force=false
#-----------------------------------------------------------------------------
# Name : pqPoolName
# Datatype : String
# Description : Only one serverpool name needs to be specified
# if create server pool option is specified.
# Comma-separated list of serverpool names if use
# server pool. This is required to
# create Parallel Query (PQ) database. Applicable to Big Cluster
# Valid values : Parallel Query (PQ) pool name
# Default value : None
# Mandatory : No [required in case of RAC service centric database]
#-----------------------------------------------------------------------------
pqPoolName=
#-----------------------------------------------------------------------------
# Name : pqCardinality
# Datatype : Number
# Description : Specify Cardinality for create server pool operation.
# Applicable to Big Cluster
# Valid values : any positive Integer value
# Default value : Number of qualified nodes on cluster
# Mandatory : No [Required when a new serverpool need to be created]
#-----------------------------------------------------------------------------
pqCardinality=
#-----------------------------------------------------------------------------
# Name : createAsContainerDatabase
# Datatype : boolean
# Description : flag to create database as container database
# Valid values : Check Oracle12c Administrator's Guide
# Default value : false
# Mandatory : No
#-----------------------------------------------------------------------------
createAsContainerDatabase=true
#-----------------------------------------------------------------------------
# Name : numberOfPDBs
# Datatype : Number
# Description : Specify the number of pdb to be created
# Valid values : 0 to 252
# Default value : 0
# Mandatory : No
#-----------------------------------------------------------------------------
numberOfPDBs=1
#-----------------------------------------------------------------------------
# Name : pdbName
# Datatype : String
# Description : Specify the pdbname/pdbanme prefix if one or more pdb need to be created
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
pdbName=PDB1
#-----------------------------------------------------------------------------
# Name : useLocalUndoForPDBs
# Datatype : boolean
# Description : Flag to create local undo tablespace for all PDB's.
# Valid values : TRUE\FALSE
# Default value : TRUE
# Mandatory : No
#-----------------------------------------------------------------------------
useLocalUndoForPDBs=true
#-----------------------------------------------------------------------------
# Name : pdbAdminPassword
# Datatype : String
# Description : PDB Administrator user password
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
pdbAdminPassword=
#-----------------------------------------------------------------------------
# Name : nodelist
# Datatype : String
# Description : Comma-separated list of cluster nodes
# Valid values : Cluster node names
# Default value : None
# Mandatory : No (Yes for RAC database-centric database )
#-----------------------------------------------------------------------------
nodelist=rac1,rac2
#-----------------------------------------------------------------------------
# Name : sehaNodeList
# Datatype : String
# Description : Comma-separated list of cluster nodes
# Valid values : Cluster node names
# Default value : None
# Mandatory : No (Yes for SEHA database)
#-----------------------------------------------------------------------------
sehaNodeList=
#-----------------------------------------------------------------------------
# Name : templateName
# Datatype : String
# Description : Name of the template
# Valid values : Template file name
# Default value : None
# Mandatory : Yes
#-----------------------------------------------------------------------------
templateName=/oradb/app/oracle/product/26.0.0/assistants/dbca/templates/New_Database.dbt
#-----------------------------------------------------------------------------
# Name : sysPassword
# Datatype : String
# Description : Password for SYS user
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : Yes
#-----------------------------------------------------------------------------
sysPassword=
#-----------------------------------------------------------------------------
# Name : systemPassword
# Datatype : String
# Description : Password for SYSTEM user
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : Yes
#-----------------------------------------------------------------------------
systemPassword=
#-----------------------------------------------------------------------------
# Name : serviceUserPassword
# Datatype : String
# Description : Password for Windows Service user
# Default value : None
# Mandatory : If Oracle home is installed with windows service user
#-----------------------------------------------------------------------------
serviceUserPassword=
#-----------------------------------------------------------------------------
# Name : emConfiguration
# Datatype : String
# Description : Enterprise Manager Configuration Type
# Valid values : CENTRAL|NONE
# Default value : NONE
# Mandatory : No
#-----------------------------------------------------------------------------
emConfiguration=
#-----------------------------------------------------------------------------
# Name : runCVUChecks
# Datatype : Boolean
# Description : Specify whether to run Cluster Verification Utility checks
# periodically in Cluster environment
# Valid values : TRUE\FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
runCVUChecks=TRUE
#-----------------------------------------------------------------------------
# Name : dbsnmpPassword
# Datatype : String
# Description : Password for DBSNMP user
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : Yes, if emConfiguration is specified or
# the value of runCVUChecks is TRUE
#-----------------------------------------------------------------------------
dbsnmpPassword=
#-----------------------------------------------------------------------------
# Name : omsHost
# Datatype : String
# Description : EM management server host name
# Default value : None
# Mandatory : Yes, if CENTRAL is specified for emConfiguration
#-----------------------------------------------------------------------------
omsHost=
#-----------------------------------------------------------------------------
# Name : omsPort
# Datatype : Number
# Description : EM management server port number
# Default value : None
# Mandatory : Yes, if CENTRAL is specified for emConfiguration
#-----------------------------------------------------------------------------
omsPort=0
#-----------------------------------------------------------------------------
# Name : emUser
# Datatype : String
# Description : EM Admin username to add or modify targets
# Default value : None
# Mandatory : Yes, if CENTRAL is specified for emConfiguration
#-----------------------------------------------------------------------------
emUser=
#-----------------------------------------------------------------------------
# Name : emPassword
# Datatype : String
# Description : EM Admin user password
# Default value : None
# Mandatory : Yes, if CENTRAL is specified for emConfiguration
#-----------------------------------------------------------------------------
emPassword=
#-----------------------------------------------------------------------------
# Name : dvConfiguration
# Datatype : Boolean
# Description : Specify "True" to configure and enable Oracle Database vault
# Valid values : True/False
# Default value : False
# Mandatory : No
#-----------------------------------------------------------------------------
dvConfiguration=false
#-----------------------------------------------------------------------------
# Name : dvUserName
# Datatype : String
# Description : DataVault Owner
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : Yes, if DataVault option is chosen
#-----------------------------------------------------------------------------
dvUserName=
#-----------------------------------------------------------------------------
# Name : dvUserPassword
# Datatype : String
# Description : Password for DataVault Owner
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : Yes, if DataVault option is chosen
#-----------------------------------------------------------------------------
dvUserPassword=
#-----------------------------------------------------------------------------
# Name : dvAccountManagerName
# Datatype : String
# Description : DataVault Account Manager
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
dvAccountManagerName=
#-----------------------------------------------------------------------------
# Name : dvAccountManagerPassword
# Datatype : String
# Description : Password for DataVault Account Manager
# Valid values : Check Oracle12c Administrator's Guide
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
dvAccountManagerPassword=
#-----------------------------------------------------------------------------
# Name : olsConfiguration
# Datatype : Boolean
# Description : Specify "True" to configure and enable Oracle Label Security
# Valid values : True/False
# Default value : False
# Mandatory : No
#-----------------------------------------------------------------------------
olsConfiguration=false
#-----------------------------------------------------------------------------
# Name : datafileJarLocation
# Datatype : String
# Description : Location of the data file jar
# Valid values : Directory containing compressed datafile jar
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
datafileJarLocation=
#-----------------------------------------------------------------------------
# Name : datafileDestination
# Datatype : String
# Description : Location of the data file's
# Valid values : Directory for all the database files
# Default value : $ORACLE_BASE/oradata
# Mandatory : No
#-----------------------------------------------------------------------------
datafileDestination=+DATA01/{DB_UNIQUE_NAME}/
#-----------------------------------------------------------------------------
# Name : recoveryAreaDestination
# Datatype : String
# Description : Location of the data file's
# Valid values : Recovery Area location
# Default value : $ORACLE_BASE/flash_recovery_area
# Mandatory : No
#-----------------------------------------------------------------------------
recoveryAreaDestination=
#-----------------------------------------------------------------------------
# Name : recoveryAreaSize
# Datatype : String
# Description : Recovery area size
# Mandatory : No
#-----------------------------------------------------------------------------
recoveryAreaSize=54525952BYTES
#-----------------------------------------------------------------------------
# Name : configureWithOID
# Datatype : Boolean
# Description : To configure with OID or not
# Valid values : TRUE / FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
configureWithOID=
#-----------------------------------------------------------------------------
# Name : pdbOptionMap
# Datatype : String
# Description : Values for DB Options indicating whether they should be included in PDB
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
pdbOptions=JSERVER:true,ORACLE_TEXT:true,IMEDIA:false,CWMLITE:true,SPATIAL:true,OMS:false,SAMPLE_SCHEMA:false,DV:false
#-----------------------------------------------------------------------------
# Name : dbOptionMap
# Datatype : String
# Description : Values DB Options indicating whether they are enabled
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
dbOptions=JSERVER:true,ORACLE_TEXT:true,IMEDIA:false,CWMLITE:true,SPATIAL:true,OMS:false,SAMPLE_SCHEMA:false,DV:false
#-----------------------------------------------------------------------------
# Name : storageType
# Datatype : String
# Description : Specifies the storage on which the database is to be created
# Valid values : FS (CFS for RAC), ASM
# Default value : FS
# Mandatory : No
#-----------------------------------------------------------------------------
storageType=ASM
#-----------------------------------------------------------------------------
# Name : diskGroupName
# Datatype : String
# Description : Specifies the disk group name for the storage
# Default value : DATA
# Mandatory : No
#-----------------------------------------------------------------------------
diskGroupName=+DATA01/{DB_UNIQUE_NAME}/
#-----------------------------------------------------------------------------
# Name : asmsnmpPassword
# Datatype : String
# Description : Password for ASM Monitoring
# Default value : None
# Mandatory : No
#-----------------------------------------------------------------------------
asmsnmpPassword=
#-----------------------------------------------------------------------------
# Name : recoveryGroupName
# Datatype : String
# Description : Specifies the disk group name for the recovery area
# Default value : RECOVERY
# Mandatory : No
#-----------------------------------------------------------------------------
recoveryGroupName=
#-----------------------------------------------------------------------------
# Name : characterSet
# Datatype : String
# Description : Character set of the database
# Valid values : Check Oracle12c National Language Support Guide
# Default value : "US7ASCII"
# Mandatory : NO
#-----------------------------------------------------------------------------
characterSet=AL32UTF8
#-----------------------------------------------------------------------------
# Name : nationalCharacterSet
# Datatype : String
# Description : National Character set of the database
# Valid values : "UTF8" or "AL16UTF16". For details, check Oracle12c National Language Support Guide
# Default value : "AL16UTF16"
# Mandatory : No
#-----------------------------------------------------------------------------
nationalCharacterSet=AL16UTF16
#-----------------------------------------------------------------------------
# Name : registerWithDirService
# Datatype : Boolean
# Description : Specifies whether to register with Directory Service.
# Valid values : TRUE \ FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
registerWithDirService=false
#-----------------------------------------------------------------------------
# Name : dirServiceUserName
# Datatype : String
# Description : Specifies the name of the directory service user
# Mandatory : YES, if the value of registerWithDirService is TRUE
#-----------------------------------------------------------------------------
dirServiceUserName=
#-----------------------------------------------------------------------------
# Name : dirServicePassword
# Datatype : String
# Description : The password of the directory service user.
# You can also specify the password at the command prompt instead of here.
# Mandatory : YES, if the value of registerWithDirService is TRUE
#-----------------------------------------------------------------------------
dirServicePassword=
#-----------------------------------------------------------------------------
# Name : walletPassword
# Datatype : String
# Description : The password for wallet to created or modified.
# You can also specify the password at the command prompt instead of here.
# Mandatory : YES, if the value of registerWithDirService is TRUE
#-----------------------------------------------------------------------------
walletPassword=
#-----------------------------------------------------------------------------
# Name : listeners
# Datatype : String
# Description : Specifies list of listeners to register the database with.
# By default the database is configured for all the listeners specified in the
# $ORACLE_HOME/network/admin/listener.ora
# Valid values : The list should be comma separated like "listener1,listener2".
# Mandatory : NO
#-----------------------------------------------------------------------------
listeners=LISTENER
#-----------------------------------------------------------------------------
# Name : skipListenerRegistration
# Datatype : Boolean
# Description : FALSE if no listener chosen for registration, else true.
# Valid values : TRUE/FALSE
# Mandatory : NO
#-----------------------------------------------------------------------------
skipListenerRegistration=false
#-----------------------------------------------------------------------------
# Name : variablesFile
# Datatype : String
# Description : Location of the file containing variable value pair
# Valid values : A valid file-system file. The variable value pair format in this file
# is <variable>=<value>. Each pair should be in a new line.
# Default value : None
# Mandatory : NO
#-----------------------------------------------------------------------------
variablesFile=
#-----------------------------------------------------------------------------
# Name : variables
# Datatype : String
# Description : comma separated list of name=value pairs. Overrides variables defined in variablefile and templates
# Default value : None
# Mandatory : NO
#-----------------------------------------------------------------------------
variables=ORACLE_BASE_HOME=/oradb/app/oracle/product/26.0.0,DB_UNIQUE_NAME=CDB,ORACLE_BASE=/oradb/app/base,PDB_NAME=,DB_NAME=CDB,ORACLE_HOME=/oradb/app/oracle/product/26.0.0,SID=CDB
#-----------------------------------------------------------------------------
# Name : initParams
# Datatype : String
# Description : comma separated list of name=value pairs. Overrides initialization parameters defined in templates
# Default value : None
# Mandatory : NO
#-----------------------------------------------------------------------------
initParams=CDB1.undo_tablespace=UNDOTBS1,CDB2.undo_tablespace=UNDOTBS2,enable_pluggable_database=true,sga_target=5998MB,db_block_size=8192BYTES,cluster_database=true,family:dw_helper.instance_mode=read-only,nls_language=AMERICAN,dispatchers=(PROTOCOL=TCP) (SERVICE=CDBXDB),diagnostic_dest={ORACLE_BASE},remote_login_passwordfile=exclusive,db_create_file_dest=+DATA01/{DB_UNIQUE_NAME}/,processes=320,pga_aggregate_target=2000MB,CDB1.thread=1,CDB2.thread=2,nls_territory=AMERICA,local_listener=-oraagent-dummy-,open_cursors=300,compatible=23.6.0,db_name=CDB,CDB1.instance_number=1,CDB2.instance_number=2
#-----------------------------------------------------------------------------
# Name : enableArchive
# Datatype : Boolean
# Description : Specifies whether to enable archive log.
# Valid values : TRUE \ FALSE
# Default value : FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
enableArchive=false
#-----------------------------------------------------------------------------
# Name : useOMF
# Datatype : Boolean
# Description : Specifies whether to use OMF or not.
# Valid values : TRUE \ FALSE
# Mandatory : No
#-----------------------------------------------------------------------------
useOMF=true
#-----------------------------------------------------------------------------
# Name : memoryPercentage
# Datatype : String
# Description : percentage of physical memory for Oracle
# Default value : None
# Mandatory : NO
#-----------------------------------------------------------------------------
memoryPercentage=40
#-----------------------------------------------------------------------------
# Name : databaseType
# Datatype : String
# Description : used for memory distribution when memoryPercentage specified
# Valid values : MULTIPURPOSE|DATA_WAREHOUSING|OLTP
# Default value : MULTIPURPOSE
# Mandatory : NO
#-----------------------------------------------------------------------------
databaseType=MULTIPURPOSE
#-----------------------------------------------------------------------------
# Name : automaticMemoryManagement
# Datatype : Boolean
# Description : flag to indicate Automatic Memory Management is used
# Valid values : TRUE/FALSE
# Default value : TRUE
# Mandatory : NO
#-----------------------------------------------------------------------------
automaticMemoryManagement=false
#-----------------------------------------------------------------------------
# Name : totalMemory
# Datatype : String
# Description : total memory in MB to allocate to Oracle
# Valid values :
# Default value :
# Mandatory : NO
#-----------------------------------------------------------------------------
totalMemory=0
